H2.15 SMT 3 Pin Female Header Right Front Left Rear Wave Type

H2.15 SMT 3 Pin Female Header Right Front Left Rear Wave Type

• High temperature resistant insulating plastic (UL94V-0) material: PBT(only meet the wave soldering process).
  High temperature resistant insulating plastic (UL94V-0) material: PA6T, PA9T, LCP(can meet the wave soldering, reflow welding two kinds of process).
  The color of insulating plastic can be divided into black, white, blue, natural color and so on.
  Hardware contact terminal material: brass (C2680) or phosphor copper (C5191), leather copper.
  Hardware contact terminal surface treatment: nickel plating first in gold or silver plating, bright tin plating, wuxi plating, semi-gold tin plating, etc.
• "Female Header is a type of connector.
  This connector is widely used in electronic, electrical, instrument in the PCB circuit board, its role is in the circuit is blocked or isolated between the circuit, play a bridge function, take up the task of current or signal transmission.
  Usually used with row pin matching, forming a board-to-board connection; Or matching with the electronic wiring harness terminal, forming a board-to-wire connection; Can also be used independently for board to board connection.
  Because different products require different specifications, there are also a variety of sizes."

,

SMT 3 Pin Female Header

Wave Type 3 Pin Female Header

Right Front pcb header female

H2.15 SMT 3 Pin Female Header Right Front Left Rear Wave Type Images
